Main Features
Speaker controller for ID, P, PS and LS series, providing digital processing from the NXAMP technology (Crossover, EQ, time alignment and speaker protection)
High-end Balanced stereo analogue inputs, AES input, USB input
High-end balanced analogue outputs for PS (Stereo) and LS (mono sum)
Automatic Amplifier Sensing with no setting required from user
Simple control from the front panel (Sub Gain, Main Gain, Crossover mode) or advanced control using USB port
DTDTU Standard Touring Digital Controller for P+ / L / ID Series
The DTD delivers advanced speaker control processing taken from the NEXO NXAMP in a compact, rack-mounting device. Providing sophisticated control over crossover, EQ and time-alignment along with speaker protection, the DTD is very easy to use, with automatic amplifier sensing and simple Sub Gain, Main Gain and Crossover Mode control available directly from the front panel (DTD-T touring version). The DTD combines efficient speaker processing with a flexible range of inputs including stereo balanced analogue inputs, an AES input and a USB port enabling direct driverless audio playback from laptops, etc.
DTD uses state-of-the-art audio processing to deliver high- precision EQ and Linear Acoustic Phase algorithms, phase- compatible with all PS and LS cabinets, along with other speakers in the NEXO range. High-end AD and DA converters and 64-bit/96kHz processing ensure an analogue in-to-analogue-out dynamic range greater than 112dB, with distortion kept to under 0.001%.
Product Features
Speaker controller for ID, P, PS and LS series, providing digital processing from the NXAMP technology (Crossover, EQ, time alignment and speaker protection)
High-end Balanced stereo analogue inputs, AES input, USB input
High-end balanced analogue outputs for PS (Stereo) and LS (mono sum)
Automatic Amplifier Sensing with no setting required from user
Simple control from the front panel (Sub Gain, Main Gain, Crossover mode) or advanced control using USB port
Product Specifications
General
Sampling Frequency and Resolution: 48/96 KHz, 64 bits internal processing precision
Signal Delay: Less than 1 ms (analogue into out) on flat setup, compatible with NXAMP latency
Frequency Response: 20 Hz to 20 KHz, +/-0.5 dB (mains out) 20 Hz to 2 KHz +/-0.5 dB (sub out)
Total Harmonic Distortion: Less than 0.001% (mains out) less than 0.02% (sub out)
Dynamic Range: 112 dB (unweighted, mains out) 107 dB (unweighted, sub out)
Crosstalk / Channel Separation: -100 dB (1KHz)
Indicators: Input signal/peak (green/red), amp in signal (green), speaker protect (yellow)
Display: White backlight graphical OLED display 96 x 16 pixels
Switch and Rotary Knobs: 3 position switch + 2 x rotary knobs
Power Supply Voltage: 90 V - 240 V 50/60 Hz
Power Consumption: 20 W max
Heat Dissipation (per hour): 20 Kcal max
Operating Temperature Range: 0°C - 40 °C
Storage Temperature Range: -20 °C - 60 °C
Analog Input Characteristics
Number of channels: 2 electronically balanced analog inputs
Connectors: 2 x XLR-F with link on XLR-M
Sampling frequency and resolution: 96 KHz / 24 bits
