BS8 8" Pendant Ball Speaker with 5m Cable 20W 100V White

« return to previous page
RCF BS8 8 Pendant Ball Speaker with 5m Cable 20W 100V White - Main Image
RCF BS8 8 Pendant Ball Speaker with 5m Cable 20W 100V White - Image 1
RCF BS8 8 Pendant Ball Speaker with 5m Cable 20W 100V White - Image 2
RCF BS8 8 Pendant Ball Speaker with 5m Cable 20W 100V White - Image 3
Price:
RRP: £97.20 inc VAT
Code:
RCFBS8
Manufacturer Code:
13133054
Brand:
RCF

Quantity required:

Main Features

  • Pendant speaker
  • For paging and background music
  • 8" diameter dual cone wide band speaker
  • Plastic body - White RAL 9010
  • Built-in transformer for 100V constant voltage connection
  • 5-metre suspension and connection cable included
Share:

BS8 8" Pendant Ball Speaker 100V/20W with 5m Cable

The BS 8 is a spherical speaker designed for suspended installation. Ideal for covering large areas, it incorporates a 200 mm (8”) loudspeaker which provides high-quality sound reproduction with excellent voice intelligibility.

Product Features

  • Pendant speaker
  • For paging and background music
  • 8" diameter dual cone wide band speaker
  • Plastic body - White RAL 9010
  • Built-in transformer for 100V constant voltage connection
  • 5-metre suspension and connection cable included

Product Specifications

Acoustical specifications

  • FREQUENCY RESPONSE (-10DB): 160 Hz ÷ 12500 Hz
  • MAX SPL @ 1M: 106 dB
  • HORIZONTAL COVERAGE ANGLE: 360°
  • SYSTEM SENSITIVITY: 93 dB

Power section

  • POWER HANDLING: 20 W RMS
  • PEAK POWER HANDLING: 80 W PEAK
  • RECOMMENDED AMPLIFIER: 40 W

Transducers

  • WOOFER: 8''

Input/Output section

  • INPUT CONNECTORS: Cable
  • OUTPUT CONNECTORS: Cable
  • CONSTANT VOLTAGE TRANSFORMER: 100 V
  • POWER SELECTION 1 (100 V): 20 W - 500 ohm
  • POWER SELECTION 2 (100 V): 10 W - 1000 ohm
  • POWER SELECTION 3 (100 V): 5 W - 2000 ohm

Standard compliance

  • CE MARKING: Yes

Physical specifications

  • COLOR: White - RAL 9010
  • HARDWARE: Carabiner and safety steel wire
  • GRILLE: Plastic
  • CABINET/CASE MATERIAL: Plastic

Size

  • DIAMETER: 250 mm / 9.84 inches
  • HEIGHT: 240 mm / 9.45 inches
  • WEIGHT: 2.3 kg / 5.07 lbs

Shipping information

  • PACKAGE WEIGHT: 3.55 kg / 7.83 lbs
  • PACKAGE DEPTH: 315 mm / 12.4 inches
  • PACKAGE WIDTH: 315 mm / 12.4 inches
  • PACKAGE HEIGHT: 300 mm / 11.81 inches
