Apprimo Touch 10 10" LCD Touch Panel PoE Black

« return to previous page
Biamp Apprimo Touch 10 10 LCD Touch Panel PoE Black - Main Image
Price:
RRP: £1,932.00 inc VAT
Code:
BIAAPPT10
Manufacturer Code:
910.1873.900
Brand:
Biamp

Quantity required:

Main Features

  • 10” capacitive touch LCD interface
  • Scratch-resistant glass
  • Several UI design templates and themes available in Project Designer software
  • Customizable user interface to fit customers’ control requirements and corporate identity
  • Fits standard single gang US, EU, and DK back boxes
  • Screen turns on automatically as someone approaches
Share:

Apprimo Touch 10 10" LCD Touch Panel PoE Black

The Apprimo Touch 10 is a 10” touch panel for any room that requires a more complex level of control, while still being a stylish and discreet interface that fits in any type of interior design. It is PoE powered and includes PIR sensors that turn the screen on automatically and adjusts the screen brightness based on the ambient light level of the room. The user interface is fully configurable with Project Designer software, which includes several themes and customizable templates to choose from. The Apprimo Touch 10 is operated by a separate Impera controller, allowing you to customize a solution that perfectly matches the customer requirements.

Product Features

  • 10” capacitive touch LCD interface
  • Scratch-resistant glass
  • Several UI design templates and themes available in Project Designer software
  • Customizable user interface to fit customers’ control requirements and corporate identity
  • Fits standard single gang US, EU, and DK back boxes
  • Screen turns on automatically as someone approaches
  • Display brightness can adjust automatically to the ambient light level
  • Magnetic wall plate for easy installation
  • PoE powered (IEEE 802.3at Class 3, 15W) for simple, single CAT5e/CAT6 cable installation
  • Firmware can be updated via mini USB port
  • Covered by Biamp Systems’ five-year warranty

Product Specifications

General

  • Display Type:  High-Contrast Capacitive Touch LCD
  • Display Size:  10” (254 mm) diagonal
  • Display Resolution:  1280x800
  • Maximum Display Brightness:  350 nits
  • Network Connection:  RJ-45 with Ethernet cable (Cat 5e and above)
  • Mini USB port:  USB 2.0
  • Sensors:  Proximity Ambient Light
  • Controller Compatibility:
    • Impera Alfa II
    • Impera Lima
    • Impera Tango
    • Impera Sierra II
  • Power:  PoE (IEEE 802.3at Class 3, 15W)
  • Included Accessories:
    • Mounting bracket and screws
    • Ejector Pin
    • USB-OTG adapter
    • Polishing cloth

Environmental

  • Ambient Operating Temperature Range: 32 - 104° F (0 - 40° C)
  • Humidity: 10-90% relative humidity (non-condensing)
  • Altitude: 0-6,600 ft (0-2000m) MSL

Physical

  • Height: 6.67 inches (169 mm)
  • Width: 9.7 inches (246 mm)
  • Depth: 1.6 inches (41 mm)
  • Weight: 1.2 lbs (560 g)

What's in the Box?

  • Mounting bracket and screws
  • Ejector Pin
  • USB-OTG adapter
  • Polishing cloth
