Tesira ATOM Central Connnection Point for Crowd Mics Software

« return to previous page

Biamp Tesira ATOM Central Connnection Point for Crowd Mics Software - Main Image

Biamp Tesira ATOM Central Connnection Point for Crowd Mics Software - Image 1

Biamp Tesira ATOM Central Connnection Point for Crowd Mics Software - Image 2

Biamp Tesira ATOM Central Connnection Point for Crowd Mics Software - Image 3

Price:: RRP: £2,500.80 inc VAT
Code:: BIATATOM
Manufacturer Code:: 911.0516.900
Brand:: Biamp

Main Features

Audio output via Euroblock, HDMI embedded audio,
3.5 minijack, or USB
Video output via HDMI®
Two HDMI connections for display mirroring
Can be monitored and managed via SageVue 2.0
Supports both local and remote participants

Crowd Mics - ATOM Central Connnection Point

Crowd Mics™ empowers audience interaction by turning smartphones into wireless microphones. Whether in the same room as the presenter or across the globe, Crowd Mics allows live event attendees to use their phone as a wireless mic, text questions, and participate in polls, providing everyone with the same great experience regardless of their location. Crowd Mics is comprised of two apps — one for event attendees and the other for moderators — and a small, pre-configured hardware host device, the ATOM.

The ATOM serves as the central connection point between the attendee and moderator apps and the room’s AV system. It supports four audio output interfaces: 3.5mm minijack, Euroblock connector, HDMI embedded audio, and USB audio. Any combination of these outputs can be used simultaneously. Optionally, the ATOM can be connected to the room’s displays via HDMI to project poll results or other event content, and can be remotely monitored and managed via SageVue™ 2.0.

Crowd Mics is perfect for the participants and moderators of presentations, lectures, panel discussions or other similar events ranging in size up to 1000 attendees.

Product Features

Audio output via Euroblock, HDMI embedded audio,
3.5 minijack, or USB
Video output via HDMI®
Two HDMI connections for display mirroring
Can be monitored and managed via SageVue 2.0
Supports both local and remote participants
CE marked, UL listed, and RoHS compliant
Covered by Biamp Systems’ two-year warranty

Benefits for Attendees

Three ways to participate
No waiting for a microphone
Intuitive user interface
Get involved without talking
Easy-to-use polling

Benefits for Moderators

Streamlines audience interactions
Choose who speaks next
Deactivate attendee mics
Create polls and publish results
Measure audience engagement

Product Specifications

General

Network Connection: Gigabit Ethernet, RJ-45
- (Cat 5 and above)
Video Output:
- Supported Resolutions: Up to 4K UHD
- Physical Interface: HDMI 2.0
- Number of Outputs: 2
Analogue Audio Output:
- Physical Interface: Euroblock
- Frequency Response (20Hz~20kHz, +4dBu): +0/-0.25dB
- THD+N (20Hz~20kHz): < 0.006%
- Dynamic Range (20Hz~20kHz, 0dB): > 96dB
- Output Impedance (balanced): 200Ω
- Maximum Output: +12dBu
- Sampling Rate: 48 kHz
- D/A Converters: 24-bit
USB:
- Version: 3.0
- Number of Ports: 2
Power Consumption (100-240VAC 50/60Hz): < 132W
Cooling: Convection
Environmental:
- Ambient Operating
- Temperature Range: 32 - 95° F (0 - 35° C)
- Humidity: 0-95% relative humidity (non-condensing)
- Altitude: 0-10,000 ft (0-3000m) MSL
