COREpar 40 USB Tri Colour RGB COB LED PAR 40W

« return to previous page
Clearance
CHAUVET DJ COREpar 40 USB Tri Colour RGB COB LED PAR 40W - Main Image
CHAUVET DJ COREpar 40 USB Tri Colour RGB COB LED PAR 40W - Image 1
CHAUVET DJ COREpar 40 USB Tri Colour RGB COB LED PAR 40W - Image 2
CHAUVET DJ COREpar 40 USB Tri Colour RGB COB LED PAR 40W - Image 3
CHAUVET DJ COREpar 40 USB Tri Colour RGB COB LED PAR 40W - Image 4
Price:
RRP: £192.00 inc VAT
Code:
CHACPAR40
Manufacturer Code:
COREPAR40USB
Brand:
CHAUVET DJ

Quantity required:

Main Features

  • Chauvet DJ COREpar 40 USB Tri-Colour LED PAR
  • Produces a full spectrum of light with unsurpassed color mixing
  • Includes a separate magnetic lens to provide flexibility
  • Withstand the harshness of traveling with a robust housing
  • Flicker-free video operation with high-frequency LED dimming
  • Easily transports in the optional CHS-30VIP Gear Bag
Share:

COREpar 40 USB

COREpar 40 USB produces a full spectrum of light with the unsurpassed colour mixing of COB (Chip-on-Board) technology and includes a separate magnetic lens to provide the flexibility to go from an ultra-wide wash to a narrow beam in seconds. High frequency LED dimming achieves smooth LED fades and ensures a flicker-free performance in video applications. Multiple control options include DMX, master/slave and sound activation modes as well as wireless control thanks to D-Fi USB compatibility. Point-and-shoot operation of static colours and automated programs is also possible with the optional IRC-6 remote control (sold separately). The unit’s robust sit-flat housing features power and DMX outlets on the side.

Product Features

  • COB (Chip-on-Board) LED produces a full spectrum of light with unsurpassed color mixing
  • D-Fi™ USB compatibility for wireless Master/Slave or DMX control
  • Included magnetic Fresnel lens allows the flexibility to go from ultra-wide to narrow beam in seconds
  • Withstand the harshness of traveling from gig to gig with a robust housing
  • Sit-flat housing design hugs the floor and features power and DMX outlets on the side of the unit
  • Achieve flicker-free video operation with high-frequency LED dimming
  • Save time running cables and extension cords by power linking multiple units
  • Point-and-shoot operation of static colors and automated programs with the optional IRC-6remote
  • Multiple control options include DMX, Master/Slave and Sound-Active modes
  • Create customized colors using the built-in LED display
  • Achieve smooth LED fading with built-in dimming curves
  • Easily transports in the optional CHS-30VIP Gear Bag
  • Compact design easily fits inside sticks of TRUSST®

Product Specifications

General

  • DMX Channels:  3 or 8
  • DMX Connectors:  3-pin XLR
  • Light Source:  1 COB LED (tri-color RGB) 40 W (2 A), 50,000 hours life expectancy
  • Strobe Rate:  0 to 33 Hz
  • PWM Frequency:  2,000 Hz
  • Beam Angle:  40° (without lens)
  • Beam Angle:  20° (with lens)
  • Field Angle:  85° (without lens)
  • Field Angle:  28° (with lens)
  • Illuminance:  243 lux @ 2 m (without lens)
  • Illuminance:  1,660 lux @ 2 m (with lens)
  • Power Linking:  21 units @ 230 V
  • Input Voltage:  100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current:  46 W, 0.4 A @ 230 V, 50 Hz

Physical & Dimensions

  • Weight:  1.6 kg
  • Size:  132 x 189 x 242 mm
  • Optional Controllers:  IRC-6
  • Approvals:  CE

What's in the Box?

  • COREpar 40 USB
  • Power cord
  • Magnetic Fresnel lens
  • Warranty card
  • Quick Reference Guide
  • Hanging bracket with mounting
