46-80 4-Zone Mixer Amp 6-Line/2-Mic/ RS232 4x80W 4Ω 2U

Cloud 46-80 4-Zone Mixer Amp 6-Line/2-Mic/ RS232 4x80W 4Ω 2U - Main Image

Cloud 46-80 4-Zone Mixer Amp 6-Line/2-Mic/ RS232 4x80W 4Ω 2U - Image 1

Cloud 46-80 4-Zone Mixer Amp 6-Line/2-Mic/ RS232 4x80W 4Ω 2U - Image 2

Price:: RRP: £1,198.80 inc VAT
Code:: CLO4680
Manufacturer Code:: 46-80EK
Brand:: Cloud

Main Features

Versatile, four-zone, rack-mounting (2U) audio mixing amplifier
Four 80W individually driven mono zone outputs
Combines simple control of background music, microphone paging and power amplification
Control up to four zones in a single unit
Extensive remote control facilities
Ideal for installed applications in pubs, bars, hotels, clubs, leisure and many more

46-80 4 Zone Integrated Mixer Amplifier

The Cloud 46-80 is a versatile, four-zone, rack-mounting (2U) audio mixing amplifier. It combines simple control of background music, microphone paging and power amplification for up to four zones in a single unit. It has extensive remote control facilities and is ideal for installation in premises such as pubs, bars, hotels, clubs, leisure and fitness centres, retail and other commercial premises, etc.

The 46-80 has four mono zone outputs, each driven by an 80 W (nominal rating) power amplifier stage: if less than four separate zones are required, the power stages may be paralleled by moving internal jumpers to permit dual stereo, quad mono or stereo + dual mono operation, with accordingly increased output power. The power stages have extensive protection circuitry to safeguard both the amplifier and loudspeakers.

Need help understanding which Cloud wall panel accessories are compatible with their range of amplifiers or mixers? Download our free guide now.

Product Features

Eight input (6 x line, 2 x mic) mixing amplifier for four zones
4 x 80 W power output, 70/100 V-line version also available (46-80T)
CXL-80T 70/100 V-line transformers may be retrofitted per-channel to 46-80
Slave mode: power amplifier stages may be paralleled in various configurations and fed from x single programme source
Peak limiter to protect power amplifier stages and loudspeakers
Utility/Loop output with independent mic/music mix and user-definable music source
Balanced, line level aux outputs (pre-power stage) from Zones 1 and 2
Four balanced and two unbalanced stereo line inputs with individual gain trim controls
Two balanced mic inputs; 15 V phantom power selectable on either or both
Zone 1 Facility Port for connection of optional remote input plates: LM-2 mic/line input + music controls, BT-1 Bluetooth input, L-1 line input, M-1 mic input
Music Mute control input (N/O or N/C) for emergency alarm system
Compatible with standard Cloud remote control panels: RL Series (music level) and RSL Series (music level and source selection), per-zone
RS-232 port for serial control of per-Zone MIC 1 muting, music level and source plus global unit standby, Music Mute and MIC 2 muting
User–selectable Automatic Power Down for maximum energy efficiency
Convection-cooled (no fan): silent in operation
