AeroCaster makes it easy and affordable for anyone to create a wireless multi-camera setup with pro-level production quality. Leveraging the A/V power of the mobile devices that everyone carries, our breakthrough system opens up a new world of creative possibilities for any livestreaming application, from online talk shows and music performances to live commerce, remote education, and beyond.

Product Features

Powerful wireless production solution with hardware control surface/audio interface and full-featured iPad app
Switch up to four wireless devices simultaneously, plus the camera on the host iPad
Supports wireless camera connections from up to four supported iOS and Android smartphones and tablets
Wirelessly share screens from computers and mobile devices via the Google Chrome web browser
Switch between cameras, media, and scenes with a variety of transition effects
Save and recall 30 scenes with titles, graphics, and picture-in-picture windows
Media pool for integrating video, audio, photos, and graphics stored on your iPad
Stream directly to YouTube, Facebook Live, Twitch, and custom RTMP channels over Wi-Fi or 4G/5G cellular networks
Intuitive hardware control surface and audio interface with two XLR inputs, 3.5 mm stereo input, and headphones and monitor outputs

Product Specifications

Aerocaster VRC-01

Connectors
- MIC 1, 2 jacks: Combo type (XLR, 1/4-inch TRS phone), balanced, phantom power (DC 48 V, 4 mA Max)
- LINE IN jack: Stereo miniature type
- MONITOR OUT jack: RCA phono type
- PHONES/HEADSET jack: Stereo miniature type (Stereo, CTIA-type)
- DC IN 5V port: USB Type-C (R)
- DEVICE port: USB Type-C (R)
Controller
- MIC 1 LEVEL fader
- MIC 2 LEVEL fader
- LINE IN LEVEL fader
- MAIN LEVEL fader
- MIC 1 COMP/LIMITER knob
- MIC 2 COMP/LIMITER knob
- MIC 1 GAIN knob
- MIC 2 GAIN knob
- LOOP BACK knob
- HEADSET/ONBOARD MIC knob
- REVERB knob
- LIP SYNC DELAY knob
- PHONES/HEADSET knob
- MIC 1 +48V switch
- MIC 2 +48V switch
Indicator
- POWER
- DEVICE
- SIG/PEAK
Nominal Input Level
- MIC 1, 2 jacks: -60 to +4 dBu (Maximum input level: +24 dBu)
- LINE IN jacks: -10 dBu (Maximum input level: +10 dBu)
Input Impedance
- MIC IN 1, 2 jacks: 10 k ohms (ANALOG GAIN < 24 dBu), 5 k ohms (ANALOG GAIN < 24 dBu)
- LINE IN jacks: 15 k ohms
Nominal Output Level
- MONITOR OUT jacks: -10 dBu (Maximum output level: +10 dBu)
- PHONES/HEADSET jack: 15 mW + 15 mW (32 ohms load)
Output Impedance
- MONITOR OUT jacks: 1 k ohms
Audio Effects
- Delay, Reverb, HPF, Noise Gate, De-Esser, Compressor, Limiter
Power Supply
- USB AC adaptor (commercially available)
- * Recommended to use an USB AC adaptor that can supply 5V, 1.0 A or more.
- USB Bus power
Current Draw
- 700 mA (AC adaptor)
- 500 mA (USB bus power)
Operation Temperature
- +0 to +40 degrees Celsius
- +32 to +104 degrees Fahrenheit
Physical & Dimensions
- Dimensions: 220(W) x 166(D) x 60(H) mm
- Weight (without cables): 600 g, 1 lb 6 oz
Accessories
- Leaflet "Read Me First"
- USB Type-C to Lightning cable
- USB Type-C to USB Type-A cable

Aerocaster Live

Video Input
- Satellite camera
- Browser source
- Built-in camera (iPad).
- * 5 inputs in total
- * Satellite cameras can be used with AeroCaster Camera or Web browser.
- * Need to install the “AeroCaster Camera” App on your iPhone and Android Phone.
- * “Browser source” use PC or mobile devices (iOS, Android OS) via Google Chrome web browser.
- * Codec:H.264 Bitrate:Up to 20Mbps
Video Processing
- RGB 4:4:4, 8-bit
- 1080/60p
- * Depends on iPad internal processing
- * Video input will be converted automatically.
Input Formats
- Up to 1080/30p
- * Automatically adjusts resolution and frame rate according to network bandwidth.
Output Formats
- Up to 1080/60p
- * Reccommend Apple USB-C Digital AV Multiport Adapter or Apple Lightning-Digital AV Adapter.
Still image and video and audio playback
- Up to 100.
- * Use still images and videos saved in the iPad.
- * File format conforms to iOS Photo Library.
- * PNG alpha channel supported.
- * Support mp4(aac), m4a(aac), mp3, wav as audio source.
Scene
- Up to 30.
- * Text, Media (Overlay), PinP, SPLIT, QUAD are either can be registered.
Video Effects
- Transition: CUT, MIX (DISSOLVE), WIPE
- DSK (overlay): Text, Media
- Composition: PinP, KEY (Luminance Key, Chroma Key), Simple telop function
- * PNG alpha channel composition supported
Audio Processing
- Sampling Rate: 24 bits, 48 kHz
Streaming Platform
- YouTube Live
- Facebook Live
- Twitch
- * Custom RTMP supported
Recording
- Format: MP4 (H.264/AAC)
- Bitrate: 1Mbps〜10Mbps
Other Functions
- (Zoom, Exposure, White Balance, Focus, LED Light, Stabilization)
- * Depends on smartphone or tablet

Operating Conditions

AeroCaster LIVE (for iPad)
- Operating System: iOS 14 or later
- CPU: Apple A12 processor or better (A12Z or better is recommended)
AeroCaster Camera (for iPhone, iPad)
- Operating System: iOS 13 or later
- CPU: Apple A10 processor or better (iPhone 7 or higher recommended)
AeroCaster Camera (for Android)
- Operating System: Android 10 or later
- CPU: Models with H.264 hardware encoder
- Others: Screen resolution 1280x720 or higher
- Equipped with two or more cameras in front and rear

Roland Pro AV

VRC-01 AeroCaster AV Streaming Mixer for up to 4 Wireless Devices

Name: VRC-01 AeroCaster AV Streaming Mixer for up to 4 Wireless Devices
Brand: Roland Pro AV
SKU: ROLAEROCAST
Price: 291.0 GBP
Availability: InStock
