The tarm 11 is a compact and robust powerhouse. It combines high performance with precision. The built-in ShowNET for controlling DMX, ArtNET, LAN, ILDA and ILDA Streaming etc. offers a wide range of applications. The tarm 11 is the perfect companion for any lighting designer. It is also ideal for rental companies, professional shows, installation projects, festivals, large stages, mapping projections and graphic installation projects.
Built with the latest RTI Semiconductor Laser Module technology!
The tarm 11 is made in Germany and is a compact show laser system that is ideally suited for top professional laser show applications of any kind. It is built with the latest RTI semiconductor laser modules that are specially designed in a way to keep spot size as well as divergence equal on both x- and y-axis. This is significantly advantageous over solutions with a very good divergence on one axis, but a bad divergence on the other. The laser modules inside the tarm 11 are different - the spot size and shape is equal for all colours and on both axis!
The beam specifications of the new tarm 11 are given with only ca. 5.0 mm diameter and 0.7 mrad divergence - which applies to both axis, so it an actual value not an average and provides higher quality results than specifications with mixed calculations. The extremely small beam diameter allows for the use of very small 4.5 mm mirrors, which results in reduced inertia and thus very good scanning performance.
The tarm 11 impresses with a guaranteed RGB output power of 11\'000 mW. Great visibility is achieved with the new RTI Semiconductor Laser modules (RSL) with special wavelengths for increased visibility: 3\'500 mW / 637 nm for a very bright red combined with 5\'000 mW / 525 nm green and a strong blue laser module with 4\'000 mW / 455 nm. The 525nm green provides a warmer green tone than the 520nm diodes and has increased visibility.
These new RSL modules with their extremely low divergence and homogenous beam shape make the tarm 11 a top professional laser system. The extremely small beam diameter of only ca. 5.0 mm allows for the use of small scanner mirrors which leads to reduced inertia and higher scan speeds. This is especially important, as the tarm 11 can be used for any kind of laser show application: Super sharp beams and vivid colours for large scale concerts and festivals but also a perfectly matched beam for crisp graphics.
The RTI Semiconductor Laser modules are maintenance free and do not come out of internal alignment.
The standard scanners can be run at a maximum of 45kpps @ 8° ILDA and a maximum scan angle of 50°. CT-6210 scanners with LAS Turboscan drivers are available as option and provide even higher scan speeds with up to 60kpps at 8° ILDA .
The powerful tarm 11 is suitable for indoor and outdoor show laser applications at concerts, festivals and other huge events. Demanding graphics projections or projections over long distances are possible without any problems, due to the extremely good divergence.
Product Features
- 11\'000 mW guaranteed power
- Complex graphics capable - 45kpps @ 8° ILDA scanners – upgradable to 60kpps
- Extremely sharp intense beams - low divergence of 0.7 mrad
- Integrated powerful mainboard with advanced configuration features (geo-correction, zone setup, color balancing, etc.) and DAC feature
- Integrated network switch for linking the control signal
- Control screen for convenient mode selection
- Rugged tour-grade compact housing
- Laser Artists\' choice
- Lighting Designers\' choice
- incl. waterproof flightcase
Product Specifications
- Guaranteed Power at aperture: 11\'000 mW
- Power Red: 3\'500 mW / 637 nm
- Power Green: 5\'000 mW / 525 nm
- Power Blue: 4\'000 mW / 455 nm
- Beam Specifications (full angle): ca. 5.0 mm / 0.7 mrad
- Scanner: 45kpps @ 8° ILDA; optional CT-6210 with LAS
- Turboscan: 60 kpps@8° ILDA, max. 60°
- Max. Scan Angle: 50°
- Operation Modes: ILDA, DMX, LAN, ArtNet, integrated SD card, stand-alone, master-slave; integrated intelligent ShowNET laser mainboard with display
- Laser Class: 4
- Laser Source: RSL module
- Accessories: Incl. waterproof flightcase, power cable, manual, key, interlock connector, full version Showeditor software license included
- Power Supply: 85 V - 250 V / AC
- Power Consumption: 350 W
- Dimensions: 350/310/168 mm
- Weight: 17.5 kg
