Compact, quick and punchy, the Focus Flex from ADJ Lighting is a versatile moving head luminaire capable of creating wash, beam and pixel effects. Designed to provide lighting designers with both flexibility and creative potential, it is ideal for event production and rental applications as well as for permanent installation in concert halls, theatres, nightclubs and churches.

The fixture is powered by an array of seven potent 40-Watt 4-in-1 RGBW colour mixing LEDs, each of which can be controlled independently. Through mixing the intensity of the primary LED colours, a huge gamut of output colours can be created to suit any mood or desired look. The fixture features a convenient Virtual CMY mode, which allows control alongside native CMY colour mixing fixtures using hardware/software CMY colour picker/palette tools. It also offers Virtual Foreground and Background Color Wheel control as well as white light output with variable colour temperature of between 2700K to 10,000K. This can be accessed either via linear control or a collection of 10 convenient presets. Meanwhile, by controlling the seven LEDs independently, the fixture can be used to generate impressive pixel-mapped effects. All of the LEDs used to construct the Focus Flex are colour calibrated to ensure uniform output of fixtures from different batches.

Motorized zoom allows the beam angle of the Focus Flex to be altered remotely between a wide 31-degrees and narrow 4-degrees, which allows it to be used for creating both broad washes and concise beams. Its extremely quick motor movement allows for the creation of stunning high-impact aerial effects, while 16-bit fine motor control ensures precise positioning.

A flexible fixture, the Focus Flex offers a range of DMX mode options (requiring between 16 and 28 control channels), appropriate to different applications, as well as a variety of customizable options, including selectable LED refresh rate and dimming modes. These are accessed through a color LCD display panel with 6-button menu interface located on the side panel of the fixture alongside a USB port which can be utilized for easy updates of future firmware releases.

Product Features

Versatile moving head luminaire capable of creating wash, beam and pixel effects
Designed to provide lighting designers with both flexibility and creative potential
Perfect for event production and rental applications as well as for permanent installation in concert halls, theatres, nightclubs and churches
Powered by an array of seven potent 40-Watt 4-in-1 RGBW colour mixing LEDs which can be controlled independently
Motorized zoom allows the beam angle of the Focus Flex to be altered remotely between a wide 31-degrees and narrow 4-degrees
Offers a range of DMX mode options (requiring between 16 and 28 control channels)

Product Specifications

Light Source

7 x 40-Watt RGBW LEDs (50,000 hr.)
CRI: 83
CT: 6600K
50,900 lux / 4° beam @ 16’
1,310 lux / 31° beam @ 16’

Features

Moving Head Pixel Wash with Pixel Effects
Electronic Strobe / Dimmer
Pan/Tilt: 540/630 x 265
Motorized Zoom: 4 ~ 31°
Colour Calibrated Pixels so units match from batch to batch
Virtual CMY DMX Control Modes
Virtual Foreground and Background Colour Wheel Control
Selectable LED Refresh Rates (900 Hz~25K Hz)
Selectable Dim Modes: Standard, Stage, TV, Arch., Theatre, Stage 2 and user settable Dim Speed (0.1S~10S)
4 Dim Curves: Square, Linear, Inv. Square and S. Curve
0-100% smooth dimming
Various strobe speeds
USB firmware update port
Fan Cooled
Antenna for WiFLY EXR Wireless DMX

Colours

Virtual CMY DMX Control Modes
Virtual Foreground and Background Colour Wheel Control
Built-In Colour Macros
2700k ~ 10,000 Liner White Colour Control
Colour Temperature Presets: 2700, 3000, 3200, 4000, 4500, 5000, 5600, 6500, 8000 and 10,000K
