The Desire Fresnel takes the best of incandescent Fresnels and adds in a colour-mixing LED engine. This classic fixture has been reimagined to bring you bright, beautiful light, cutting-edge technology, and a wide zoom range. We reworked how the lens and lamp work together in Desire Fresnel, so the light you get is bright and efficient through the entire zoom range. Providing more lumens regardless of angle, this fixture is up to 25% more efficient than traditional Fresnel optical systems. Add in the Lustr X8 colour system with deep red LEDs, City Theatrical’s wireless DMX Multiverse® technology, and an intuitive user interface, and we know this will become your new favourite fixture.

Product Features

• Lustr X8 full-colour array
• 5 inch or 7 inch glass Fresnel lens aperture
• Smooth wash
• Built-in manual zoom
• Multiverse wireless DMX control
• Intuitive user interface
• Mobile app setup with NFC
• Standard 5/10 year LED fixture warranty

Product Specifications

• Source
  • LED details:  Lumileds LUXEON® C
  • Max lumens:  5,158

  • Lumens per watt:  31.6

  • L70 rating (hours to 70% output):  54,000 hours
• Colour
  • Colours used:  Deep Red, Red, Amber, Lime, Green, Cyan, Blue, Indigo
  • Colour temperature range:  1900–10450 K
  • Calibrated array:  Yes
  • Red shift:  Yes (selectable)
• Optical
  • Beam angle range:  14°–49°
  • Gate size:  N/A
  • Aperture size:  127 mm (5 in)
  • Pattern projection:  No
  • Pattern size:  N/A
  • Camera flicker control/Hz range:  Yes: 5 kHz, 25 kHz

• Control
  • Input method:  5-Pin XLR, Multiverse wireless and NFC
  • Protocols:  DMX-512, RDM, City Theatrical Multiverse, NFC
  • Modes (footprint):   6 modes (1–12 channels)
  • RDM configuration:  Yes
  • UI type:  Full colour display
  • Local control:  Yes
  • Onboard presets:  Yes (12)
  • Onboard sequences:  Yes
  • Onboard effects:  Yes
  • FixtureLink:  Yes

• Wireless
  • Band:  2.400–2.480 GHz
  • Range:  100 m indoors, 500 m line of sight (subject to conditions)
  • Max receivers
    • DMX:  No limit
    • RDM:  Varies by transmitter used
    • Multiverse SHoW Baby®:  585
    • Multiverse Transmitter:  5,000
  • Broadcast power:  100 mW
• Electrical
  • Voltage range:  100–230 VAC
  • Input method:  AC via powerCON® TRUE1® TOP
  • Inrush (first half-cycle):
    • 120 V: 26 A (first half-cycle)
    • 230 V: 55 A (first half-cycle)
  • Fixtures per circuit:  7 (link up to 6 via Power Thru connector) Note: TRUE1 connector rated for 20 A (120 V / 60 Hz) and 16 A (230 V / 50 Hz)

  • Wattage (typical/standby):
    • 120 V: 163.3 W
    • 230 V: 160.7 W

  • Current draw:
    • 120 V: 1.39 A
    • 230 V: 0.76 A
• Thermal
  • Ambient operating temp:  0°C to 40° C (32°F to 104° F)
  • Fan (controllable):  Yes (yes)
  • Droop compensation:  Yes
  • Average dB:  8.4–37.7 dBA
  • BTUs/hour:  557
• Regulatory and Compliance
  • Approved regulatory standards:
    • cETLus Listed
    • CE Compliant
    • FCC Compliant
• Warranty
  • Fixture:  5 years
  • LED array:  10 years
• Physical
  • Materials:  Cast and extruded aluminium
  • Colour options:  Black, white, silver, or custom colour
  • Mounting options:  Yoke
  • IP rating:  IP20
  • Dimensions (HxWxD):  394 x 254 x 349/444 mm

  • Weight:  7.8 kg (17.2 lb)

What's in the Box?

• Desire DFL5
• Yoke
• Power cable
