In the rig or on the floor, live or on camera, the lightweight COLORdash PAR H7X RGBWAUV LED wash from Chauvet Professional is a portable six pound package that delivers a broad palette of subtle to saturated colors with beautiful precision. Flawlessly smooth 16-bit fades with four selectable dimming curves. Flicker-free output with multiple PWM frequencies. Punch up a hot pink, mix a delicate pastel, pick a perfectly calibrated Kelvin colour temperature, or trigger intense strobe effects. With RDM to remotely choose its DMX personality and an OLED display to easily read its onboard menu, the COLORdash PAR H7X is a die-cast workhorse that withstands the rigours of real world use while offering convenient operation and excellent performance.

Product Features

• Rugged RGBWA-UV LED wash for events
• Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
• RDM (Remote Device Management) for added flexibility
• Selectable, smooth dimming curves for eliminate flicker and choppiness in fades
• Easy to read OLED display with password protection and touchscreen interface
• Advanced optics provide exceptional colour mixing and high efficiency
• Double-bracketed yoke with omega bracket doubles as floor stand

Product Specifications

Optical

• Light Source: 7 LEDs (hex-colour RGBAW+UV) 84 W, (505 mA), 50,000 hours life expectancy
• Colour Temperature (range): 2800 to 10,000 K
• Colour Temperature (at full): 14,329 K
• Beam Angle: 22.7°
• Field Angle: 37.6°
• Lumens: 2738
• Illuminance (total): 522 lux @ 5 m
• Selectable PWM: 600 Hz, 1.2K Hz, 2K Hz, 4K Hz, 6K Hz, 25K Hz

Dynamic Effects

• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Strobe Rate: 0 to 20 Hz
• Standalone Colour Mixing: Yes
• Colour Temperature Presets: Yes
• Dim Modes: 4
• Built-in Automated Programs: Yes
• Customizable Programs: No

Connections

• Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
• Power Output: Seetronic Powerkon IP65
• Data Connectors: 3- and 5-pin XLR, 3- and 5-pin IP65 XLR
• Cable Length (power): 5 ft (1.5 m)

Control

• Control Protocol: DMX, RDM
• DMX Channels: 6ch ,8ch ,9ch ,13ch, or 14ch
• Modes/Personalities: 5 personalities (6ch ,8ch ,9ch ,13ch, or 14ch)

Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 20 units @ 120 V; 34 units @ 208 V; 38 units @ 230V
• Power and Current: 70 W, .592 A @ 120 V, 60 Hz
• Power and Current: 67 W, .344 A @ 208 V, 60 Hz
• Power and Current: 67 W, .312 A @ 230 V, 50 Hz

Certifications / Qualifications

• CE, MET, FCC, UKCA, FCC
• IP Rating: IP20, dry location
• Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

Physical & Dimensions

• Dimensions: 10.16 x 9.45 x 4.57 in (258 x 240 x 116 mm)
• Weight: 6 lb (2.7 kg)
• Exterior Colour: Black
• Housing Material: Aluminium alloy, Aluminium die-cast
• Accessory Holder/Gel Frame Size: 6.5 in (165 mm)

What's in the Box?

• Colordash Par H7X
• Seetronic powerkon IP65 power cord
• Gel frame holder
• Gel frame
