COLORado 3 Solo from Chauvet Professional uses advanced zooming optics and three 60 W RGBW engines to project an intense and fully homogenized beam. IP rated power and data connectors, and full convection cooling ensure a reliable and silent performance indoors and out, in a wide range of applications, from theatrical to outdoor festival productions.

Product Features

• Zooming RGBW LED wash for touring, rental, and production, indoors or out
• Completely homogenized wash with superior colour mixing and zoom
• 8° to 45° smooth and fast zoom
• All environment operation with IP rated power and DMX connections
• Colour temperature presets, from 3200 K to 10000 K
• Selectable, smooth dimming curves for programming versatility
• OLED display with password protection

Product Specifications

Optical

• Light Source: 3 LEDs (quad-colour RGBW) 60 W, (4.4 A), 50,000 hours life expectancy
• Beam Angle: 4° to 34°
• Field Angle: 8° to 45°
• Zoom Angle: 8° to 45°
• Illuminance (4°): 15,280 lux @ 5 m
• Illuminance (34°): 313 lux @ 5 m
• Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 2400 Hz, 6000 Hz, 25,000 Hz

Dynamic Effects

• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Zoom: Motorized
• Strobe Rate: 0 to 25 Hz
• Standalone Colour Mixing: Yes
• Colour Temperature Presets: Yes
• Dim Modes: 5
• Built-in Automated Programs: Yes
• Customizable Programs: Yes
• Recall Custom Programs: Yes

Physical & Dimensions

• Dimensions: 250 x 314 x 413 mm
• Weight: 9 kg
• Exterior Colour: Black
• Housing Material: Magnesium
• Accessory Holder/Gel Frame Size: 191 mm

Connections

• Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Power Output: Seetronic Powerkon IP65
• Data Connectors: 3- and 5-pin XLR
• Cable Length (power): 1.5 m

Control

• Protocol(s): DMX, RDM
• DMX Channels: 9, 12, or 17
• Modes/Personalities: 4 personalities (HSIC, SSP, TOUR, TR16, STD.Y)

Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 8 units @ 120 V; 14 units @ 208 V; 15 units @ 230 V
• Power and Current: 187 W, 1.580 A @ 120 V, 60 Hz
• Power and Current: 181 W, 0.909 A @ 208 V, 60 Hz
• Power and Current: 175 W, 0.869 A @ 230 V, 50 Hz

Certifications / Qualifications

• CE, MET
• IP Rating: IP65, outdoor/wet, with pressure equalizing M12 GORE® valve

What's in the Box?

• COLORado 3 SOLO
• Seetronic Powerkon IP65 power cord
