All the rugged IP65 reliability of our production-grade COLORado family in a fixture featuring the power of lime to achieve better whites and more accurate colour rendition. A new RGBL LED source paired with optics optimized for its upgraded zoom system delivers higher output than ever before, from a road-tested design with new touring-friendly features that include backlit buttons for easier work in the dark.

Product Features

• High-performance RGBL LED zoom wash for touring, rental, and production -indoors or out
• High-power with smooth and even colour mixing
• 3.9° to 52.6° smooth and fast zoom
• All environment operation with IP-rated power and DMX connections
• Easy mounting using traditional clamps, quick connecting omega bracket, or split yoke floor stand
• Selectable, smooth dimming curves for programming versatility
• OLED display with back lit buttons, including focus mode and password protection

Product Specifications

Optical

• Light Source:  7 LEDs (quad-colour RGBL), 8.4 to 13 W, (2.7 A), 50,000 hours life.
• Colour Temperature (range):  2800 to 8000 K
• Colour Temperature (at full):  5882 K
• CRI (3200K):  83
• Beam Angle:  3.9° to 38.5°
• Field Angle:  6° to 52.6°
• Cutoff Angle:  7.3° to 58.9°
• Zoom Range:  3.9° to 52.6°
• Lumens (3.2°):  3350
• Lumens (39.9°):  5974
• Illuminance (3.9°):  27,567 lux @ 5 m
• Illuminance (38.5°) :  657 lux @ 5 m
• Selectable PWM:  600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 25,000Hz
• Dynamic Effects
• Dimmer:  Electronic
• Shutter/Strobe:  Electronic
• Zoom:  Motorised
• Focus:  Electronic
• Strobe Rate:  0 to 30 Hz
• Standalone Colour Mixing:  Yes
• Colour Temperature Presets:  Yes
• Dim Modes:  4
• Dim Curves:  4
• Built-in Automated Programs:  Yes

Construction / Physical

• Dimensions:  16.34 x 10.94 x 8.30 in (415 x 278 x 210.84 mm)
• Weight:  14.2 lb (6.4.0 kg)
• Exterior Colour:  Black
• Housing Material:  Magnesium diecast
• Accessory Holder/Gel Frame Size:  7.5 in (190.5mm)

Connections

• Power Connection:  Edison (Local) plug to Seetronic Powerkon IP65
• Power Input:  Seetronic Powerkon IP65
• Power Output:  Seetronic Powerkon IP65
• Data Connectors:  5-pin XLR
• Cable Length (power):  5 ft (1.5 m)
• Software Connection:  USB

Control

• Control Protocol:  DMX, RDM
• DMX Channels:  1CH, 5CH1, 5CH2, 7CH, 11CH, 12CH, 13CH, 16CH or HSV
• Modes/Personalities:  9 personalities (1CH, 5CH1, 5CH2, 7CH, 11CH, 12CH, 13CH, 16CH, HSV)

Electrical

• Input Voltage:  100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking:  units @ 120 V; units @ 208 V; units @ 230 V
• Power and Current:  258 W, 2.17 A @ 120 V, 60 Hz
• Power and Current:  255 W, 1.28 A @ 208 V, 60 Hz
• Power and Current:  260 W, 1.20 A @ 230 V, 50 Hz

Certifications / Qualifications

• CE, MET, FCC
• IP Rating:  IP65, outdoor/wet, with pressure equalizing M12 GORE valve
• Temperature (Ambient):  -4 °F to 122 °F (-20 °C to 50 °C)

What's in the Box?

• COLORado 3 Quad Zoom
• Seetronic Powerkon IP65 power cord
• Omega bracket
• Gel frame holder (7.5 in/190.5 mm accessories)
