New for 2020, Club XS+ models incorporate all of the great features of the standard Club range, now with the inclusion of a DSP On/Off foot switch socket and an aesthetic overhaul, redesigned control knobs and finished in Studiomaster digital black.

Compact, portable mixing consoles featuring 5 to 16 inputs, Bluetooth connectivity, on-board DSP effects and USB/SD card playback and recording functions. 3 band EQ, 2 auxiliaries, balanced mic/line connectors, compressor control, and a useful mute switch on all Mic and line input channels, and 2 band EQ with 2 auxiliaries for both stereo channels. There are also balanced XLR connectors for the main outputs, jack outputs for auxiliaries and control room, and phono connectors for record and playback.

Ultra compact, light weight, high quality and extremely versatile, the Club XS is the perfect mixer for any live performance and home recording situation.

Product Features

• 16 inputs: 12 mic channels, 2 stereo channels
• 3 Auxiliary busses for monitoring and internal/external effects processing
• Professional balanced outputs
• High quality microphone pre amps with enhanced compression and gain controls and 3 band EQ on all microphone channels
• 60mm smooth faders
• PFL and Mute control on every channel
• 16 in built DSP effects
• Foot switch socket for DSP on/off control
• Internal power supply
• BLUETOOTH playback facility
• USB/SD CARD media module for playback / recording
• DSP EFFECTS 16 quality reverb, delay and stereo effects
• DSP ON/OFF footswitch socket to easily turn on or off your effects
• COMPRESSOR and 100Hz high pass fi-filter on all mic channels
• MUTE button on all channels
• 3 BAND EQ on mic channel for superior tone adjustments
• 2 BAND EQ on stereo channels to add warmth to your instruments
• AUX & DSP OUTPUT for a monitor mixes and external fx
• STEREO RETURN extra inputs with a simple level control
• RCA/PHONO playback and record ability
• HEADPHONES and control room output for full monitoring
• +48V phantom power on mic channel for condenser microphones

Product Specifications

• Inputs: 16
• Mic Inputs: 12
• Stereo Inputs: 2
• Mic Gain Range: 6dB to 50dB
• Line Gain Range: 10dB to 34dB
• EIN: -100dB
• Frequency Responce: 10Hz – 20kHz (+1/-3dB)
• THD Mic Channel: <0.1%
• Signal to Noise Ratio: 80dB
• Output Levels: Max +26dB (Bal), +20dB (unBal)
• EQ: Hi 12kHz, Mid 2.5kHz, Lo 45Hz, Lo cut 80Hz
• USB/SD: MP3 Audio playback
• Record: To USB drive or SD card (128kbps mono)
• DSP Effects: 16 DSP effects
• Power Requirements: 100V – 240V ~
• Dimension W*H*D: 525 x 80 x 390 (mm)
• Weight: 7.3kg
