The XDJ-AN bridges the gap to club DJing with a familiar workflow that supports multiple music sources, including StreamingDirectPlay and CloudDirectPlay, for seamless cloud access.

Product Features

• Access to streaming services - With StreamingDirectPlay, you can access tracks from compatible streaming services directly on the XDJ-AN and mix them seamlessly with music from other sources.
• Cloud-based playlist editing - Using Cloud Library Sync with a compatible rekordbox subscription plan, it’s easy to manage your cloudbased music library directly from the XDJ-AN. The changes you make on the unit, such as adding Hot Cues and editing playlists, are automatically synchronised with the cloud.
• Works with mobile apps - The XDJ-AN works with DJ apps such as rekordbox for iOS and djay for iOS. The unit also supports the DJM-REC app for live streaming and recording.
• Club-standard layout and media compatibility - With a layout based on the professional CDJ and DJM series gear, the XDJAN helps ensure a smooth transition from DJ controllers to club-standard setups. You can connect a laptop to perform with DJ software such as rekordbox for Mac/Windows, Serato DJ Lite, or djay Pro, or you can play music stored on USB drives.
• Built-in SonicLink transmitter - Thanks to the built-in transmitter for SonicLink, AlphaTheta’s ultra-lowlatency wireless audio technology, you can pair the XDJ-AN with compatible headphones and start monitoring wirelessly right away.
• High-quality sound and flexible connectivity - The XDJ-AN delivers clear and powerful audio at all volume levels. As well as its XLR outputs for professional equipment and RCA outputs for connecting to a wide range of audio devices, it features Bluetooth input/output for extra flexibility.

Product Specifications

• Input / Output terminals
  • Input:  MIC × 1 (1/4″ TRS jack)
  • Output:
    • MASTER × 2 (XLR × 1, RCA × 1)
    • PHONES × 1 (3.5 mm stereo mini jack)
  • USB:
    • USB Type-C × 1 (Storage)
    • USB Type-C × 1 (PC/Mac/Mobile device)
    • USB Type-C × 1 (Power supply)
• Wireless LAN (Wi-Fi)
  • Supported standards:  IEEE 802.11 a/b/g/n/ac
  • Frequency band used:  2.4 GHz / 5 GHz
• Bluetooth
  • Wireless system:  Bluetooth Classic
  • Compatible codecs:  SBC, AAC
  • Maximum transmission distance:  Approx. 20 m in unobstructed locations
  • Frequency band used:  2.4 GHz
• SonicLink
  • Maximum transmission distance:  Approx. 5 m in unobstructed locations
  • Frequency band used:  2.4 GHz
• Performance Control
  • Channels:  2
  • Deck control:  2
  • Main display:  7-inch touchscreen (WSVGA 1024 × 600)
  • Jog wheel size:  132 mm
  • Sound Colour FX
    • SPACE
    • DUB ECHO
    • SWEEP
    • NOISE
    • CRUSH
    • FILTER
  • Beat FX
    • REVERB
    • ECHO
    • FLANGER
• Main Specifications
  • Max. external dimensions (W × D × H):  638 × 359.2 × 89.9 mm (25.1” × 14.1” × 3.5”)
  • Main unit weight:  5.2 kg (11.5 lb)
  • Frequency characteristic:  20 Hz – 20 kHz (USB, MIC)
  • S/N ratio:  112 dB (USB)
  • Total harmonic distortion:  0.003 % (USB)
  • Compatible software
    • rekordbox for Mac/Windows (Hardware Unlock – no license needed)
    • rekordbox for iOS (DJing via USB cable connection is only supported on the iOS version – no license needed)
    • djay Pro for Mac and Windows (subscription needed)
    • djay for iOS (subscription needed)
    • Serato DJ Lite (no license needed)
    • Serato DJ Pro (subscription needed)

What's in the Box?

• Power cord
• AC adapter
• Quick Start Guide
• Precautions for Use
