The Tesira® AMP-450BP is a four-channel PoE+ (IEEE 802.3at Class 4, 30W) conferencing amplifier. The output channels are software configurable, including selectable power versus channel count. Suitable for air handling spaces, the amplifier can be located close to ceiling speakers if desired, and can even be mounted directly to the back can of a Desono™ C-IC6 loudspeaker. Each AMP-450BP comes with an optional mechanical enclosure to protect electrical connections and comply with typical code requirements for above-ceiling installations. The AMP-450BP includes an internal limiter, and is capable of providing 3 watts of continuous power to all four channels. The Tesira AMP-450BP is also capable of operating in a burst mode to handle peak signals, providing up to 50 watts (4Ω load) or 30 watts (8Ω load) per channel. The amplifier serves as a dedicated endpoint in a Tesira system, making installations easier to design, support, and maintain. The AMP-450BP is ideal for TesiraFORTÉ®-equipped conference rooms or other applications where sound reinforcement is needed.

Product Features

• Four channels; 3 watts of continuous power per channel
• Burst mode to handle peak signals in accordance with ANSI/CTA-2006-B; supports up to 50 watts (4Ω load) or 30 watts (8Ω load) per channel
• Powered by PoE+ (IEEE 802.3at Class 4, 30W)
• RJ-45 connectors enable termination-free connections to compatible speakers like the Desono C-IC6
• Class D amplifier topology
• Fanless operation
• BPAK accessory included
• Audible locate function available on the front panel
• Includes internal limiter function
• Software-selectable power versus channel count
• Evaluated to the requirements of UL 2043 and is suitable for use in air handling spaces
• Configurable via Tesira software
• CE marked, UL listed, and RoHS compliant
• Covered by Biamp Systems’ five-year warranty

Product Specifications

General

• Network Connection: RJ-45 with Ethernet cable (Cat 5e and above)
• Number of Channels: 4
• Connectors: RJ-45
• Amplifier Topology: Class D
• Burst Power Output (per ANSI/CTA-2006-B @ 1kHz):
  • 4Ω (per channel): 50W
  • 8Ω (per channel): 30W
• Continuous Power Output:
  • Single Channel Driven (4Ω, 8Ω): 15W
  • Dual Channel Driven, (4Ω, 8Ω): 7W
  • Four Channel Driven, (4Ω, 8Ω): 3W
• THD+N (20Hz-20kHz, at continuous power): < 0.3%
• Frequency Response (20Hz-20kHz): ± 1dB
• Dynamic Range (20Hz-20kHz BW): > 90dB
• Minimum Operational Load: 4Ω
• Intermodulation distortion (SMPTE): <0.3%
• Cross Talk (channel to channel @ 1kHz): < -90dB
• Cooling: Convection
• Power: PoE+ (IEEE 802.3at Class 4 , 30W)
• Indicators:
  • Power Indicator (Green/Yellow/Red LED)
  • Amp Status Indicator (Green/Yellow/Red LED)

Physical

• Dmensions:
  • Height: 1.2 inches (30mm)
  • Width: 7.7 inches (195mm)
  • Depth: 4.7 inches (120mm)
  • Weight: 1.5 lbs (0.7 kg)
• Environmental:
  • Ambient Operating Temperature Range: 32 - 104° F (0 - 40° C)
  • Humidity: 0-95% relative humidity (non-condensing)
  • Altitude: 0-10,000 ft (0-3000m) MSL
• Compliance:
  • FCC Part 15B (USA)
  • UL and C-UL listed (USA and Canada)
  • CE Marked (Europe)
  • KCC (Korea)
  • RoHS Directive (Europe)
  • Evaluated to the requirements of UL 2043 and is suitable for use in air handling spaces
