Our newest STRIKE design introduces dynamic dual-layer pixel effects with a punchy flair that brings totally new and unique looks to our tour-proven STRIKE family of IP65-rated strobes and blinders. STRIKE V features dual LED diodes, under a variable electronic frost plate that can change beam angles instantly at the press of a button, and together offer fresh new multicolor creative possibilities. Advanced eye-candy effects, vibrant colour washes, and stunning strobe capabilities from a motorized 180° tilting strobe/wash hybrid designed for powerful performance in the most demanding applications and conditions.

Product Features

• Fully featured, high-power, 180° tilting hybrid strobe/wash with IP65 rating for all-weather use
• 48 individually controllable pixels across two layers of LEDs
• Variable electronic frost for added eye candy effects
• Included magnetically attachable stealth filter for hiding the LEDs when not in use
• Multiple mounting locations and repositionable yoke with ¼ turn adaptors for creative and convenient rigging options in vertical and horizontal orientations
• RDM control over DMX for fixture reporting
• 16-bit dimming of master dimmer for smooth control of fades
• Easy-to-use OLED display
• Rugged design for years of rough use in the most extreme conditions.
• Adjustable Pulse Width Modulation (PWM) for added flexibility
• USB port for fixture software updates
• Built-in alignment pins to insure perfectly straight linear arrays
• Failsafe Ethernet connectivity allows for data to pass even if fixture power is lost

Product Specifications

Optical

• Light Source: 24 LEDs top plate (quad-color RGBW), 6W, 50,000 hours life expectancy
• Light Source: 24 LEDs bottom plate (quad-color RGBW), 50W, 50,000 hours life expectancy
• Beam Angle (Combine): 9.9°
• Beam Angle (Dot): 105.7°
• Beam Angle (Cell): 9.9°
• Beam Angle (w/E-Frost Combine): 50.3°
• Beam Angle (w/E-Frost Dot): 103.1°
• Beam Angle (w/E-Frost Cell): 46.8°
• Field Angle (Combine): 17.6°
• Field Angle (Top Plate): 153.1°
• Field Angle (Cell): 17.5°
• Field Angle (w/E-Frost Combine): 125°
• Field Angle (w/E-Frost Dot): 155.6°
• Field Angle (w/E-Frost Cell): 117.2°
• Lumens (Combine): 19,589
• Lumens (Dot): 1,912
• Lumens (Cell): 17,127
• Lumens (w/E-Frost Combine): 13,406
• Lumens (w/E-Frost Dot): 1,633
• Lumens (w/E-Frost Cell): 15,769
• Illuminance (Combine): 16,779 lux @ 5 m
• Illuminance (Dot): 29 lux @ 5 m
• Illuminance (Cell): 16,789 lux @ 5 m
• Illuminance (w/E-Frost Combine): 539 lux @ 5 m
• Illuminance (w/E-Frost Dot): 26 lux @ 5 m
• Illuminance (w/E-Frost Cell): 536 lux @ 5 m
• Selectable PWM: 1000Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25000 Hz, 64,000 Hz

Dynamic Effects

• Tilt: 180°
• Tilt Ranges: 0° to 180°
• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Strobe Rate: 0 to 30 Hz
• Standalone Colour Mixing: Yes
• Dim Modes: 4
• Built-in Automated Programs: Yes

Certifications / Qualifications

• CE, MET, ROHS, FCC
• IP Rating: IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
• Temperature (Ambient): 14 °F to 113 °F (-10 °C to 45 °C)
• Temperature (Ambient): 14 °F to 113 °F (-10 °C to 45 °C)

Construction / Physical

• Dimensions: 16 x 7.3 x 12.2 in (407 x 187.4 x 310 mm)
• Weight: 36 lb (16.3 kg)
• Exterior Colour: Black
• Housing Material: AZ91D Magnesium diecast

What's in the Box?

• STRIKE V
• Seetronic Powerkon IP65 power cord
• Omega bracket
• Stealth filter
