The Laserworld ScanBar 10RGB is a white-light RGB laser with analogue modulation. It's controlled via four DMX profiles, making it easy to integrate into existing lighting setups. Each beam output features its own X/Y scan set with 25kpps at 8°. In addition to single-beam projection, the Laserworld ScanBar 10RGB offers > 100 pre-set patterns.
The Laserworld ScanBar 10RGB is equipped with RGB laser diode modules, with each RGB module delivering a power of 5 x 450 mW / 638 nm red, 5 x 600 mW / 525 nm green, and 5 x 950 mW / 450 nm blue. These power values are measured after the apertures.
Controlled via DMX profiles, the Laserworld ScanBar 10RGB is compatible with all current DMX controllers. This Laserworld ScanBar 10RGB can be effortlessly integrated into an existing lighting setup. It's a great visual effect for large events.

Product Features

• 10 W guaranteed power
• 5 x RGB Diode Modules
• 5 x X/Y Scanners - 25kpps at 8°
• Full colour mixing - analogue modulation
• Extremely sharp beams - low divergence
• Professional DMX with four different profiles

Product Specifications

• Guaranteed Power at aperture:  10'000 mW
• Power Red:  5 x 450 mW / 638 nm
• Power Green:  5 x 600 mW / 525 nm
• Power Blue:  5 x 950 mW / 450 nm
• Beam Specifications:  4 mm / 1.1 mrad
• Scanner:  25kpps at 8°
• Laser Source:  Diode
• Laser Class:  4
• Operation Modes:  DMX, stand-alone, master-slave
• Basic Patterns:  > 100
• Power Supply:  85 V - 250 V AC, 50/60 Hz
• Power Consumption:  150 W
• Dimensions:  1000 x 152 x 105 mm (L x W x H)
• Weight:  12 kg

What's in the Box?

• Power cable
• Manual
• Interlock
• Key
