The JBL Pro SoundBar PSB-1 is a cost-effective, commercial-grade active soundbar designed specifically for use in applications such as hotel guestrooms and cruise ship staterooms. With an optimised feature set targeting the unique requirements of these applications, the Pro SoundBar reduces the cost and complexity found in consumer-grade soundbars while providing excellent sound quality, security, and reliability.

The all-in-one design of the Pro SoundBar provides full-range sound without the need for a separate subwoofer, providing excellent quality audio while minimising sound transfer to neighboring rooms. For further volume management, the Pro SoundBar offers a 4-position volume limiting switch to control the maximum volume output of the soundbar. The Pro SoundBar supports both fixed and variable source volume for maximum TV compatibility. Controls for the volume switch and source volume selection can be covered by a lockout plate to prevent tampering by anyone other than the support staff.

Product Features

• Full-range stereo sound without the need for a subwoofer
• Application-specific features for guestrooms and staterooms
• Fixed/variable source volume modes
• IR learning for use with any remote
• Neutral room décor aesthetic
• Volume limiting
• Lockout plate prevents tampering
• Internal, universal power supply for global installations, no “wall worts”
• Securely mounts to wall/table to prevent theft or drifting on cruise ships
• Mounting hardware, audio cables, cable adapters, and remote included
• Auto standby for reduced energy usage
• Non-absorbent materials for easy cleaning

Applications

• Hotel guestrooms
• Cruise ship staterooms
• Meeting rooms and public spaces

Product Specifications

General

• Frequency Response (-10dB): 42Hz – 20kHz
• Frequency Response (±3 dB): 56Hz – 20kHz
• Maximum Peak SPL(0dBV): 90 dB-SPL at 1m (0 dBV input; Max Volume setting, one channel)
• Input Connectors: 2 x RCA (left & right)
• Nominal Input Sensitivity: -10 dBV for 85 dB-SPL at 1m (Max Volume setting)
• HF Driver Size: 2 x 19 mm (0.75”) Soft Dome Tweeter (one per channel)
• LF Driver Size: 4 x 51 mm (2.0”) Low-Frequency Driver (two per channel)
• Power Amp: 20W per Channel, Class D
• AC power: Input: 100V-240VAC, 50/60Hz, 1.5ASleep Mode Power: 0.25W at 100VAC; 0.36W at 240VAC

Physical

• Dimensions (H x W x D): 90 x 900 x 65mm (3.54 x 35.4 x 2.55 in). See Owner’s Manual for dimensional drawing.
• Weight: 1.8kg (4.0lbs)
• Shipping Weight: 2.5kg (5.5lbs)
• Enclosure Material: Injection-Molded ABS
• Enclosure Finish: Black
• Mounting/Installation: Two included brackets, desk/table or on-wall mounting. See Owner’s Manual for installation diagrams.
