The Parlé™ VBC 2800 is an all-in-one conferencing bar featuring Biamp Audio Intelligence and Biamp Video Intelligence that delivers high performance AV experiences across all meeting spaces up to and including large conference rooms.

The VBC 2800 features a dual 50 MP + 8 MP ePTZ camera system that clearly sees everyone, even further down long conference tables. The ePTZ system also features up to 16x digital zoom, and AI auto framing technology automatically switches between ultrawide and wide-angle cameras for the best shot. With integrated Acoustic Echo Cancellation (AEC) and AI Noise Reduction, the VBC 2800 uses a 27-microphone array and Biamp Beamtracking™ technology to actively track and intelligently mix conversations from around the room.

The VBC 2800 also features Biamp Launch™, an automated tuning system that optimizes the audio to each unique conferencing space.

Product Features

• Beamtracking technology actively tracks and intelligently mixes conversations
• AI noise reduction algorithm for clear voice reproduction
• Low distortion smart stereo speakers
• Biamp Launch for one touch automatic tuning
• LED indications for mute status and camera activity
• Automatic privacy shutter and LED indicators for mute status and camera activity
• Dual 4K ePTZ camera system that can stream 2160p @30fps
• Ultrawide angle 120° horizontal field of view
• 50 MP wide angle lens with 86° horizontal field of view
• Electronic Pan/Tilt/Zoom with 16x zoom
• Auto framing technology to keep participants in frame
• Analog audio input
• Discrete output for Assistive Listening Systems
• Easy connectivity with a UC system or BYOM hub with a single USB cable
• 3-year warranty

Product Specifications

Loudspeaker

• Beamwidth: Nominal Beamwidth (H x V): 180° x 180°
• Transducers: 2x 2.5 inches (60 mm) full range
• Sensitivity: (@ 1m, 2.83V): 84 dB

Video

• Supported Resolution:
  • 720p @ 30 fps
  • 1080p @ 30 fps
  • 2160p @ 30 fps
• Camera:
  • DUAL CAMERA SYSTEM
  • Ultrawide Lens
  • Wide Angle Lens
• Physical Interfaces:
  • USB 3.0: 1x Type C
  • Analog Audio Input 1x 3.5mm mono unbalanced
  • Assistive Listening Feed: 1x 3.5mm mono balanced

Camera

• Diagonal Field of View:
  • ULTRAWIDE LENS: 150°
  • WIDE ANGLE LENS: 110°
• Horizontal Field of View:
  • ULTRAWIDE LENS: 122°
  • WIDE ANGLE LENS: 86°
• Verticle Field of View:
  • ULTRAWIDE LENS: 88°
  • WIDE ANGLE LENS: 69°
• Image Sensor:
  • ULTRAWIDE LENS: 8 Megapixel
  • WIDE ANGLE LENS: 50 Megapixel
• Focus Distance:
  • Minimum Focus Distance: ULTRAWIDE LENS: 100 cm
  • WIDE ANGLE LENS: 300 cm
• Digital Zoom Max Zoom:
  • ULTRAWIDE LENS: 3x
  • WIDE ANGLE LENS: 16x
• Lens Cap: Automated Privacy Shutter
• Positioning:
  • Autoframing capabilities
  • Electronic Pan/Tilt/Zoom
  • UVC controlled
• Indicators: Camera Active Indicator (White/Off LED)
• Microphone: Microphone Technology: 27-Element Digital Array
• Impedance: Nominal Impedance: 4Ω
• THD+N: (@ 1kHz): < 0.2%
• Frequency Response: (57 Hz - 20 kHz): -10 dB
• SPL: Rated Maximum SPL (@ 1m): 90 dB (continuous)
• Sampling Rate: 48 kHz

Compliance

• Certifications
  • FCC Part 15B (USA)
  • CE Marked (Europe)
  • UL and C-UL listed (USA and Canada)
  • RoHS Directive (Europe)
  • REACH (Europe)

Physical & Dimensions

• Height: 3.9 inches (100 mm)
• Width: 37 inches (940 mm)
• Depth: 2.5 inches (64 mm)
• Weight: 9.6 lbs (4.4 kg)
• Ambient Operating Temperature Range: 32 - 104° F (0 - 40° C)
• Humidity: 0-90% (non-condensing)
• Altitude: 0-10,000 ft (0-3000m) MSL
• Power
• SOURCES:
  • USB-C: 60W
  • External Power Supply: 100-240VAC 50/60Hz
  • (12VDC, 4.74A)
