Ovation F-915VW is a high-power, variable white Fresnel-style fixture that utilises our unique 6-colour LED system. This fixture projects a bright, beautifully soft field of light in nearly any temperature of white with high CRI and CQS making it ideal for theatres and TV studios. Each Colour Temperature can be further adjusted for +/- green and a motorised zoom with a 17° – 85° field range allows you to add light where it is needed. The Colour Temperature and hue along with zoom and output can be controlled via DMX or on-board dials.

Product Features

• New Model: Now with powerCON® TRUE1
• Variable white LED Fresnel lighting fixture for theatre, film and production
• Soft and even field of light
• Smooth, motorised zoom from 17° to 85° beam range
• Colour Temperature Presets from 2800 K to 8000 K with high CRI and CQS
• Beautiful 16-bit dimming
• Proprietary LED engine delivers tremendous, equal output at all colour temperatures
• Easy to use on board control of colour temperature, zoom and dimming
• +/- Green adjustment via DMX or on-board control
• Independent colour control over the 6-colour engine when a splash of colour is needed
• RDM (Remote Device Management) for added flexibility
• Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
• Virtually silent operation for use in studio and theatre applications

Product Specifications

Optical

• Light Source:  89 LEDs (6 red, 15 orange-red, 8 green, 12 blue, 16 royal blue, 32 lime) 3 W, (960 mA), 50,000 hours life expectancy
• Colour Temperature (range):  2800 to 8000 K
• CRI:  88-92
• Beam Angle:  17° to 54°
• Field Angle:  30° to 85°
• Zoom Range:  17° to 85°
• Lumens (30°):  4,143
• Lumens (85°):  6,792
• Illuminance (30°):  1,748 lux @ 5 m
• Illuminance (85°):  414 lux @ 5 m
• Selectable PWM:  600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz

Dynamic Effects

• Dimmer:  Electronic
• Zoom:  Motorised
• Strobe Rate:  0 to 27 Hz
• Standalone Colour Mixing:  Yes
• Colour Temperature Presets:  Yes
• Dim Modes:  4
• Built-in Automated Programs:  No

Connections

• Power Connection:  Edison (local) plug to Seetronic Powerkon IP65
• Power Input:  Seetronic Powerkon IP65
• Power Output:  Seetronic Powerkon IP65
• Data Connectors:  3- and 5-pin XLR
• Cable Length (power):  5 ft (1.5 m)

Control

• Control Protocol:  DMX, RDM
• DMX Channels:  1, 4, 6, 7, 9, 13, 16 or 18
• Modes/Personalities:  8 personalities (1, 4, 6, 7, 9, 13, 16, 18)

Electrical

• Input Voltage:  100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking:  5 units @ 120 V; 8 units @ 208 V; 9 units @ 230 V
• Power and Current:  271 W, 2.3 A @ 120 V, 60 Hz
• Power and Current:  262 W, 1.433 A @ 208 V, 60 Hz
• Power and Current:  258 W, 1.209 A @ 230 V, 50 Hz

Certifications / Qualifications

• CE, MET, FCC, UKCA
• IP Rating:  IP20, dry location
• Temperature (startup):  -4 °F to 113 °F (-20 °C to 45 °C)
• Temperature (operating):  -22 °F to 113 °F (-30 °C to 45 °C)

Construction / Physical

• Dimensions:  22.41 x 12.59 x 10.82in (569.44 x 320 x 275 mm)
• Weight:  18.6 lb (8.5 kg)
• Exterior Colour:  Black
• Housing Material:  Aluminium alloy, Aluminium die-cast

What's in the Box?

• Ovation F-915VW
• Seetronic Powerkon IP65 power cord
• Gel frame (7.5 in/191 mm accessories)
