Useful for times when DMX lighting isn’t needed, this effective utility light is powered by direct line voltage and can be dimmed via off-the-shelf phase-cut or triac dimmers. Projecting a soft flood light that minimises shadows, Ovation 2WL offers selectable 3200K, 4000K, and 5600K colour temperatures that provide wide-spectrum, high-CRI lighting.

Product Features

• Effective utility light for use when DMX lighting isn’t needed
• Three selectable colour temperatures (3200, 4000, 5600K) providing wide-spectrum, high-CRI lighting
• Soft, flood lighting minimizes shadows
• Use with direct line voltage and can be dimmed via off-the-shelf phase cut or triac dimmers

Product Specifications

Optical

• Light Source:  960 LEDs (CW, WW)
• Colour Temperature (3200k):  3217 K
• Colour Temperature (4000k):  3960 K
• Colour Temperature (5600k):  5584 K
• CRI (3200K):  95.3
• CRI (4000K):  95.2
• CRI (5600K):  94.0
• Beam Angle:  107.4°
• Field Angle:  158.7°
• Lumens (3200k):  10,564
• Lumens (4000k):  10,954
• Lumens (5600k):  11,328
• Illuminance 3200k):  158 lux @ 5 m
• Illuminance (4000k):  164 lux @ 5 m
• Illuminance (5600k):  169 lux @ 5 m

Dynamic Effects

• Dimmer:  External Dimmer (phase cut or triac compatible)
• On-board Colour Temperature Selection

Connections

• Power Connection:  Edison (local) plug to Seetronic Powerkon IP65
• Power Input:  Seetronic Powerkon IP65
• Power Output:  Seetronic Powerkon IP65
• Cable Length (power):  5 ft (1.5 m)

Electrical

• Input Voltage:  100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking:  13 units @ 120 V; 21 units @ 208 V; 23 units @ 230 V
• Power and Current:  103 W, 0.91 A @ 120 V, 60 Hz
• Power and Current:  99 W, 0.55 A @ 208 V, 60 Hz
• Power and Current:  98 W, 0.51 A @ 230 V, 50 Hz
• Breaker Size:  T2.5 A, 350 V

Certifications / Qualifications

• CE, MET, FCC, RoHs
• IP Rating:  IP20, dry location
• Temperature (Ambient):  -4 °F to 113 °F (-20 °C to 45 °C)

Construction / Physical

• Dimensions:  17.51x 11.06 x 5.47 in (445 x 281 x 139 mm)
• Weight:  10.2 lb (4.6 kg)
• Exterior Colour:  Black
• Housing Material:  Aluminium alloy
• Accessory Holder/Gel Frame Size:  14.375 x 8.50 x 0.125 in (365.125 x 216 x 3.175 mm)

What's in the Box?

• Ovation 2WL
• Seetronic Powerkon power cable
• Omega Bracket with mounting hardware
