Drawing from decades of experience crafting innovative, premium analog gear, Yamaha originally developed their new discrete Class-A microphone preamps for professional use in their high-end recording equipment. Utilizing an inverted Darlington circuit design, the newly-refined D-PRE mic preamps deliver a fat, rich, smooth tone that gives the MGP Series a significant advantage over any other mixer in its class. With Yamaha proprietary X-pressive EQ they\'ve managed to capture ultimate analog authenticity by unlocking the mysterious secret behind the expressive sound shaping capabilities of sought-after classic EQ modules.

At the heart of the MGP compact configuration, Yamaha have taken an innovative new approach to the utilization of digital technology in an analog mixer; adding high-resolution effects, iPod/iPhone integration and the superb functionality of the new Stereo Hybrid Channel to the warmth and musicality of premium analog sound. The MGP Series represents the ultimate balance of the converging technologies that are the heart and soul of Yamaha extraordinary achievements in professional audio.

Product Features

• Input channels: 24 Line Inputs (16 mono, 4 stereo), 16 Mic Inputs with 48V phantom power and HPH per channel.
• Output channels: 1 ST out, 1 Mono out, 1 Monitor out, 6 AUX sends, 4 Group out, 1 Phones out, 2 Matrix out, 1 Stereo CH insert out, 16 Mono
• Buses: 1 Stereo bus, 4 Group buses, 6 AUX Sends (AUX5 and AUX6 are switchable to FX1 and FX2).
• Robust, impact-resistant, powder-coated metal chassis.
• Internal universal power supply for worry-free operation around the globe, even in unsteady voltage environment.
• Discrete class A “D-PRE” mic preamps with an inverted darlington circuit.
• “X-pressive EQ” based on Yamaha’s VCM (Virtual Circuit Modeling) technology.
• Professional “1-knob compressors” with LED indicators.
• Dual digital effects processors: advanced “REV-X” reverb and 16 “SPX” effects
• Stereo Hybrid Channel with DSP offers following unique functions:
  • “Priority Ducker” allows a microphone to take priority over another sound source automatically.
  • “Leveler” to adjust volume levels of different tracks automatically.
  • “Stereo Image”to optimize the pan balance to MONO/BLEND, useful for installed sound.
• Digital connectiviry for iPhone/iPod with a dedicated terminal.
  • “MGP Editor” App for detailed control of the console’s DSP settings with iPhone/iPod.
  • High quality digital playback from iPhone/iPod.
• USB device recording and playback. (WAV/MP3)
• Graphic EQ with selctable 9 flex-band or 14 fixed band mode.
• Multi-band compressor.

Product Specifications

• INPUT CHANNELS
  • LINE INPUT: 24 (16 MONO + 4 STEREO)
  • MIC INPUT: 16
  • MONO INPUT (MIC/LINE): 16 (CH1-16)
  • STEREO INPUT (LINE): 4 (CH17-24)
  • MONO CH INSERT INPUT: 16
  • STEREO CH INSERT INPUT: 2
  • RETURN: 1 STEREO
  • TALKBACK IN: 1
• OUTPUT CHANNELS
  • STEREO OUT: 1
  • MONO OUT: 1
  • MONITOR OUT [L, R]: 1
  • AUX SEND: 6
  • GROUP OUT: 4
  • PHONES OUT: 1
  • MATRIX OUT: 2
  • STEREO CH INSERT OUT [L, R]: 1
  • MONO CH INSERT OUT: 16
• BUS
  • STEREO: 1
  • GROUP: 4
  • AUX: 6 AUX Sends (AUX5 and AUX6 are switchable to FX1 and FX2)
• USB AUDIO - USB IN/OUT: USB Device, iPod / iPhone
• PHANTOM POWER: +48V per channel
• POWER REQUIREMENTS: 100-240V 50Hz/60Hz
• POWER SUPPLY TYPE: Internal Universal Power Supply
• POWER CONSUMPTION: 86W max
• DIMENSIONS W x D x H: 819mm x 565mm x 169mm (32.2" x 22.2" x 6.7")
• NET WEIGHT: 15.5kg (34.2lbs)
• INCLUDED ACCESSORIES: AC Power Code, Owner’s manual
• SOFTWARE APPLICATION MGP EDITOR: Yes (Download on the App Store)
• OPTIONAL ACCESSORIES: LA1L
• OPERATING TEMPERATURE: 0 to 40˚C

What's in the Box?

• AC Power Code
• Owner’s manual
