The MA-60 is an exciting new development from Cloud Electronics, combining for the first time the proven versatility of Cloud mixer-amplifiers in a single compact (2U, half-rack width) unit, and at a very competitive price point.

The MA-60 will find many applications in the Retail, Hospitality, Licensed Premises and other entertainment markets and is the most feature rich of the Utility Mixer/Amps on the market which also offers the best sound quality and the traditional Cloud reliable.

Single Zone, 60w, 4Ω Output as Standard with Optional 70/100v Internal Transformer (CXL-60T).

Need help understanding which Cloud wall panel accessories are compatible with their range of amplifiers or mixers? Download our free guide now.

Product Features

Four-input mixer-amplifier with integral 60w, 4Ω mono power amplifier
Optional 70/100v Internal Transformer (CXL-50T)
Gain trims on all inputs
Electronically-balanced mic input
3.5 mm jack input (LINE 2) for MP3 player, laptop, etc.
Overall HF & LF EQ adjustment
Short-to-ground access connector or VOX-triggered paging on mic input
Selectable LINE 4 priority over other music inputs
Music Mute control input (NO or NC) for interface to emergency system
Compatible with standard Cloud remotes – RL-1 (music level) and RSL-4 (music level and source selection)
Electronically-balanced pre-amp output
Transformer-isolated auxiliary output with independent mic and music level control - for use with telephone MOH systems
Aux output source selection (internal jumper) – fixed source or follow main output
Dimensions (mm) - 213.0 wide x 88 high (2U) x 278 deep (+ connectors & knobs)
Optional Rack Kits (RE-S & RE-L)

Product Specifications

Line inputs

Frequency Response
- Low-Z output: +0/-1 dB, 20 Hz to 20 kHz (65 Hz filter out)
- 100/70/50 V-line output (with CXL-50T transformer fitted): +0/-3 dB, 20 Hz to 20 kHz (65 Hz filter out)
Distortion
- Low-Z output: <0.05% @ 1 kHz, 1 dB below full power (80 kHz bandwidth)
- High voltage output: <0.05% @ 1 kHz, 1 dB below full power (80 kHz bandwidth)
Sensitivity: 195 mV (-12 dBu) to 2.0 V (+8 dBu)
Input Gain Control: 20 dB range
Input Impedance: 47 kohms
Headroom: >20 dB
Noise: -93 dB, 22 Hz to 22 kHz; measured at speaker output, relative to full power

Microphone inputs

Frequency Response
- Low-Z output: -3 dB @ 100 Hz (3rd. order filter); -1 dB @ 20 kHz
- High voltage output: -3 dB @ 100 Hz (3rd. order filter); -2 dB @ 20 kHz
Distortion: <0.05% @ 1 kHz, 1 dB below full power (80 kHz bandwidth)
Gain: 40 dB range
Input Impedance: >2 kohms (balanced)
Phantom Power: 15 V, switchable per-input by jumpers
Headroom: >20 dB
Noise: -127 dB EIN, 22 Hz to 22 kHz (150 ohms)

Outputs

Output Power
- Low impedance output: 60 W @ 1 kHz & <0.07% THD+N
- 100/70/50 V-line output: 50 W @ 1 kHz & <0.07% THD+N (Requires CXL50T)
Equalisation: HF: +/-10 dB @ 5 kHz LF: +/-10 dB @ 100 Hz
Protection: Dynamic level signal limiter max gain reduction of 20 dB, Thermal protection, IV limiting & short circuit protection, Switch on delay

Physical & Dimensions

Power input: 230 V, 115 V, 100 V versions available
Fuse Rating: 230/120 V - T2A H
Fuse Type: 20 mm x 5 mm
Cooling: Convection cooled, vents top and bottom
Dimensions (w x h x d): 213 mm x 88 mm (2U) x 278 mm (plus connectors and knobs)
Shipping Dimensions (w x h x d): 270 mm x 140 mm x 380 mm
Weight: 3.5 kg
Shipping Weight: 4.2 kg
