The Electro-Voice EKX-15P Powered PA speaker is part of EV EKX series of loudspeakers, which combines legendary EV sound quality and reliability -- all in a compact package suitable for a wide range of sound reinforcement scenarios, including musicians/DJs and live/club/installed sound applications.

EV-engineered components, Signal Synchronized Transducers (SST) waveguide design, and Class D amplifiers (up to 1500 W) coupled with QuickSmartDSP all work together to provide precise coverage and superior sound quality at high SPLs. EV award-winning industrial design - with robust wood enclosures and durable EVCoat finish - ensures that EKX speakers look as great as they sound.

Product Features

• QuickSmartDSP features best-in-class processing, EV’s signature single-knob user interface, and intuitive menu navigation via LCD.
• High-efficiency 1500 W Class D power amplifier delivers up to 134 dB peak SPL on the EKX-15P via high-sensitivity transducers designed and engineered by EV.
• Intelligent thermal management with a variable-speed fan controlled by multiple onboard sensors, ensuring superior performance and reliability in demanding environmental conditions.
• EV-patented Signal Synchronized Transducers™ (SST) waveguide design provides precise and consistent coverage.
• Lightweight, compact 15-mm wood enclosure with internal bracing, durable EVCoat finish, eight M10 threaded mounting points, aluminum pole mounts, and all-metal handles.

Product Specifications

General

• Maximum SPL: 134 dB Maximum SPL is measured at 1 m using broadband pink noise at maximum output
• Power Consumption: 1.8 A Current rating is 1/8 power
• Power Rating: 1500 W
• Frequency Response (-3 dB): 55 Hz - 18 kHz Hz Full space measurement using the music DSP preset
• Frequency Response (-10 dB): 48 Hz - 20 kHz Hz Full space measurement using the music DSP preset
• Coverage (Nominal -6 dB) H: 90 °
• Coverage (Nominal -6 dB) V: 60 °
• LF Transducer: EVS-15M 381 mm (15 in)
• HF Transducer: DH-1M 1-inch titanium compression driver
• Crossover Frequency: 1.7 k Hz
• Connector Type: (1) Stereo RCA input, (2) XLR/TRS combo jack, and (1) XLR link output
• Enclosure Material: 15 mm, plywood with EVCoat
• Grill: 18 AWG steel with powdercoat
• Suspension: (8) M10 threaded mounting points

Physical & Dimensions

• Height: 685mm
• Width: 432mm
• Depth: 429mm
• Weight: 24.4kg
