The VENU360 provides all the processing and flexibility you need between your mixer and amplifiers to optimize and protect your loudspeakers. With the latest advancements in dbx’s proprietary AutoEQ™ and AFS™ algorithms, additional input channels, ethernet control via an Android,® iOS,® Mac,® or Windows® device, and updated wizards, the DriveRack VENU360 continues the DriveRack legacy of great-sounding, powerful, and affordable loudspeaker management processors, for a whole new generation.

Product Features

Input Processing

• dbx Compression
• AFS™ (Advanced Feedback Suppression)
• 31-Band Graphic EQ
• 12-Band Parametric EQ (with narrow notch capabilities)
• Subharmonic Synthesis
• Backline Delay
• Noise Gate

Output Processing

• Crossover (supports full range up to mono 6-way systems)
• 12-Band AutoEQs (8 AutoEQ bands, 4 User bands)
• dbx Compression
• Automatic Gain Control
• Subharmonic Synthesis
• Noise Gate
• Tower Delays (up to 1000ms per output)
• 8-Band Parametric EQs (used for speaker tunings)
• dbx Limiting
• Driver Alignment Delays

Tested Wireless Routers

• Dlink 636L
• Dlink Cloud router 2000
• Cisco / linksys: WRT54G2V1
• Netgear WGR614 v7
• Netgear WNR 1000

Product Specifications

• Input: (3) analog line inputs/(2) AES digital inputs (shared connectors), (1) RTA mic input
• Input Connectors: (3) female XLRs (2 selectable between analog/AES digital audio formats), (1) female XLR RTA mic input
• Input Type: Electronically balanced/RF filtered
• Input Impedance: > 30 kΩ, balanced line to line
• Max Input Level (line inputs): > +28 dBu, balanced, ≤1% THD
• Output: (6) Line Outputs
• Output Connectors: Male XLR
• Output Type: Electronically balanced, RF filtered
• Output Impedance: 120 Ω, balanced line to line
• Max Output Level: +22 dBu, balanced, ≤1% THD
• Latency: Analog input to output: 2.57 ms (48 kHz), 2.28 ms (96 kHz); Digital AES input to output: 2.31 (48 kHz), 2.15 ms (96 kHz)
• Operating Voltage: 100-240 VAC 50/60 Hz
• Power Consumption: 18 W
• Unit Weight: 5.48 lbs. (2.49 kg)
• Shipping Weight: 7.10 lbs. (3.22 kg)
• Dimensions: 1.75” (H) x 8.0” (D) x 19” (W), 4.4cm (H) x 20.32cm (D) x 48.26cm (W)
