The Shure Beta 98AMP is a compact, high-output, condenser microphone for professional sound reinforcement and studio recording. An extremely uniform cardioid polar pattern provides excellent gain before feedback, off-axis rejection of unwanted noise, and performance in high sound pressure level (SPL) environments.

The Beta 98AMP features an integrated preamplifier with XLR connection, a flexible gooseneck, and is packaged with the A75M Universal Microphone Mount accessory for precision adjustments and minimal stage clutter. For use with drums, percussion, and other fixed-placement applications.

Product Features

Uniform cardioid polar pattern provides maximum gain-before-feedback and rejection of off-axis sound for smooth high-end response and control
Precision-engineered design features integrated preamplifier and XLR connector to maximize setup efficiency while minimizing stage clutter
Frequency response tailored for drums and percussion applications with a wide dynamic range for use in high SPL environments
Flexible gooseneck for precise placement and easy adjustment
Ships with A75M Universal Microphone mount with quick release, for versatile and secure instrument and/or stand mounting
Furnished with snap-fit windscreen and zipper pouch

Product Specifications

Type: Electret Condenser
Frequency Response: 20 to 20,000 Hz
Polar Pattern: Cardioid
Output Impedance: 150 Ω
Sensitivity at 1kHz, open circuit voltage, typical: -50.5 dBV/Pa(2.5 mV)
Maximum SPL 1 kHz at 1% THD:
- 2500 Ω load: 157.5 dB SPL
- 1000 Ω load: 153.0 dB SPL
Signal-To-Noise Ratio: 63 dB
Dynamic Range at 1kHz:
- 2500 Ω load: 126.5 dB
- 1000 Ω load: 122.0 dB
Clipping Level at 1 kHz,at 1% THD:
- 2500 Ω load: 12.5 dBV
- 1000 Ω load: 7.5 dBV
Self Noise equivalent SPL,A-weighted,typical: 31.0 dB SPL-A
Common Mode Rejection 10 Hz to 100 kHz: ≥60 dB
Power Requirements: 11–52 V DC phantom power [4], 5.5 mA
Polarity: Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
Net Weight: 130 g(4.6oz.)
