The Mackie ProFX6v3 6-Channel Professional Effects Mixer with USB is the ultimate affordable solution for live sound, home recording, and content creators. Now with our renowned Onyx mic preamps that offer 60db of headroom, everything from gain hungry mics to guitars will sound better than ever. The new GigFX™ effects engine offers 24 built-in FX for even more options for adding the finishing touch. Record your tracks in 24-Bit/192kHz quality with 2x4 USB I/O plus zero-latency hardware monitoring for easy overdubs. Both ProTools® | First and Waveform™ OEM recording software/plugin packages are included.

The Mackie ProFX6v3 Professional Effects Mixer with USB is the ultimate affordable solution for live, home recording, and content creators. Now with Onyx mic preamps that offer 60db of headroom, single-knob compression, and 24 built-in FX. Record your tracks in 24-Bit/192kHz quality with 2x4 USB I/O and zero-latency hardware monitoring. Both ProTools® | First and Waveform™ OEM recording software/plugin packages are included.

The Mackie ProFX6v3 features Onyx Mic Preamps, 192kHz 2x4 recording, 24 built-in FX, and simple single-knob compression with ProTools® | First and Waveform™ OEM recording software/plugin packages included.

Product Features

The Ultimate Affordable Mixer for Everyone

• Designed for maximum versatility making it perfect for live sound, home recording, content creation, and live streaming

Renowned Onyx Mic Preamps

• Equipped with 2 Onyx Mic Pres offering up to 60db of gain and ultra-low noise performance
• Perfect for microphones popular with content creators that require high-gain preamps

High-Resolution GigFX™ Effects Engine

• With 24 different FX options, from reverbs to delays, adding some drama to your sound is easy easy… easy….. easy…….. easy (Delay, get it?)

24-Bit / 192kHz 2x4 USB Recording Interface

• Lay down your tracks in incredible 24-Bit / 192kHz quality for the cleanest recordings possible
• 2x4 USB I/O allows you to create two custom mixes on your computer to send back in to the mixer, great for situations when you need to monitor specific tracks during playback in addition to the full mix

Effortless Latency-Free Monitoring

• With a single knob, you can blend between monitoring your computers output and a direct feed from the mixer
• Great for recording overdubs alongside a pre-recorded track

The Essential Mixing Tools You Need

• 2-band EQ (80Hz and 12kHz) on channels 1/2
• Hi-Z switches allows direct connection of guitars, basses, and other instruments
• 100Hz low-cut filter and 48V phantom power on all mic channels
• Line inputs on channel 3/4
• Stereo 1/8” input on channel 5/6
• Headphone output with separate level and blend control

Record and Produce Like a Pro

• ProTools® | First and Waveform™ OEM professional software and plugin packages included
• The Musician Collection for ProTools | First includes 22 plugins like BBD Delay, Gray Compressor, and Eleven Lite
• The DAW Essentials™ Bundle for Waveform™ OEM includes 16 powerful plugins like Equaliser, Compressor, Reverber8, and Limiter

Signature Rugged Design

• Legendary Mackie “Built-Like-A-Tank” design
• Solid steel chassis protects your investment
• Tough ABS side protection

Accessories

• Protective bag (sold separately)

Product Specifications

Frequency Response

• Mic input to any output (gain at unity, +0 dB / -1 dB): 20 Hz to 30 kHz

Attenuation and Crosstalk

• Adjacent Inputs @1 kHz: -90 dB
• Inputs to Outputs @1 kHz: -80 dB
• Fader Off @1 kHz: -75 dB
• Mute Switch / Break Switch Mute @1 kHz:
  • -90 dB
  • -100dB

Common Mode Rejection Ratio (CMRR)

• Mic in to Main out, max gain, 1 kHz: 70 dB

Maximum Levels

• All inputs: +22 dBu
• Main Mix XLR: +28 dBu
• All other outputs: +22 dBu

Impedances

• Mic in: 3.3 kΩ
• Channel Insert Return: 10 kΩ
• All other inputs: 20 kΩ
• Phones out: 25 kΩ
• All other outputs:
  • 120 Ω Unbalanced
  • 240 Ω Balanced

Digital Effects

• Number of Presets: 24

Channels

• Number of Channels:
  • ProFX6v3: 6 Channels
  • ProFX10v3: 10 Channels
  • ProFX12v3: 12 Channels
  • ProFX15v3: 15 Channels
  • ProFX22v3: 22 Channels
  • ProFX30v3: 30 Channels

Physical

• Dimensions (H x W x D):
  • ProFX6v3: 74 x 191 x 213 mm
  • ProFX10v3: 84 x 272 x 302 mm
  • ProFX12v3: 102 x 330 x 376 mm
  • ProFX15v3: 112 x 450 x 434 mm
  • ProFX22v3: 112 x 612 x 434 mm
  • ProFX30v3: 112 x 820 x 434 mm
• Weight:
  • ProFX6v3: 1.2 kg
  • ProFX10v3: 2.2 kg
  • ProFX12v3: 3.6 kg
  • ProFX15v3: 6.9 kg
  • ProFX22v3: 9.0 kg
  • ProFX30v3: 12.0 kg

For full specifications please view the pecsheet\' loacted in the \'Downloads\' tab.
