ZX1-90 8" 2-Way Speaker Excluding Bracket 90x50° 200W Black

« return to previous page
Electro-Voice ZX1-90 8 2-Way Speaker Excluding Bracket 90x50° 200W Black - Main Image
Electro-Voice ZX1-90 8 2-Way Speaker Excluding Bracket 90x50° 200W Black - Image 1
Electro-Voice ZX1-90 8 2-Way Speaker Excluding Bracket 90x50° 200W Black - Image 2
Price:
RRP: £460.56 inc VAT
Code:
ELEZX190B
Manufacturer Code:
F.01U.267.021
Brand:
Electro-Voice

Quantity required:

Main Features

  • Smooth, wide frequency response
  • Ideal for mains, fills, or monitors
  • Velocity-compensated port for exceptional LF
  • Long-excursion weather-treated EV8L woofer
  • 1.25-inch DH2005 titanium HF compression driver
  • Passive crossover with full-band overload protection
Share:

ZX1-90 8" 2-Way Loudspeaker 90x50° 200W Black

The Electro Voice ZX1-90 is an 8-inch two-way passive speaker. This compact, lightweight, flexible sound system was designed to deliver a superb, mature sound despite its compact dimensions. Thanks to the construction of the polypropylene cabinet, in combination with the 8-inch woofer and 1-inch compression driver, it delivers the acoustic performance of a 12-inch speaker, and even that of some 15-inch cabinets! Since the ZX1-90 also has protection on board, you can rest assured that it will always perform without giving out on you.

Product Features

  • Smooth, wide frequency response
  • Ideal for mains, fills, or monitors
  • Velocity-compensated port for exceptional LF
  • Long-excursion weather-treated EV8L woofer
  • 1.25-inch DH2005 titanium HF compression driver
  • Rotatable 90º x 50º horn for flexible coverage
  • Passive crossover with full-band overload protection
  • High sensitivity, 123 dB maximum SPL
  • Power handling: 200 W continuous, 800 W peak
  • High-impact polypropylene enclosure
  • Compact monitor-friendly wedge shape
  • Integrated pole mount adapter and pocket handle
  • Metric mounting inserts (4)

Product Specifications

General

  • Chassis Size: 203.2 mm (8")
  • Colour: Black
  • Input Connections: Parallel Neutrik® NL4
  • Speaker Type: Full-range, Mid-High, Two-Way, Wedges
  • Frequency Response (-3 dB): 60-20000Hz
  • Frequency Response (-10 dB): 48-20000Hz
  • Internal Crossover: Yes
  • Recommended High-Pass Frequency: 40Hz
  • Sensitivity 1 W/1 m: 94dB
  • Max. SPL/1m (calc): 123dB
  • Coverage (Nominal -6 dB) H: 90° Rotatable
  • Coverage (Nominal -6 dB) V: 50° Rotatable
  • Rotatable Horn: Yes
  • System Power Handling (Continuous/Program/Peak): 200//800 Watts
  • LF Transducer: 8-inch EV8L
  • HF Transducer: 1.25-inch DH2005
  • Crossover Frequency: 1700 Hz
  • Nominal Impedance (Passive): 8Ω
  • Minimum Impedance: 6Ω
  • Enclosure Material: High Impact Polystyrene
  • Flying: No
  • Outdoor: No
  • Grill: Polyester Powder Coated, 18GA Galvanized Steel

Physical & Dimensions

  • Height: 457mm
  • Width: 282mm
  • Depth: 264mm
  • Weight: 8.4kg
